The DE-STA-CO StrongHold SELECT spring advance work supports have
a spring loaded
plunger which contacts the workpiece as it is loaded into the
fixture.The spring keeps the
plunger in contact with the work piece, allowing for variations
between workpieces.To support
any externally applied loads, the surrounding sleeve grips the
plunger and holds it in place.
SELECT Features Include:
-
Advanced seals and wipers utilize a special, highly wear-resistant
construction for
long cycle life and 5000 PSI operation.
- 700
PSI minimum recommended pressure
- Rigid
construction limits elastic deflection under load.
- High
cycle-life spring design for reliable plunger return.
- Advanced
metal treatment with superior wear and corrosion resistance.
- MRO
interchange design.
- 040-1-1650
threaded body model may be side or bottom plumbed.
- Lower
flange models may be side plumbed or bottom manifold mounted.
|
|
