MANUAL CLAMPS
Rubber Latch

MODELS 326, 336, 346

DE-STA-CO “T ” handle rubber latches provide vibration and sound dampening and compensation for sever misalignment. The latch handle is made of an ozone resistant synthetic rubber and the base and keeper are formed of passivated stainless steel. Operation is easy: simply pull on handle and stretch to slide bulb of rubber handle into the keeper.

  • Automatically compensates for misalignment
  • Dampens vibration
  • Dampens sound
  • Easy to operate
  • Ozone resistant synthetic rubber
  • Durometer 70 plus/minus 5
  • Stainless steel passivated components
  • Three models
  • Low cost
  • Max. temperature rating 250° F (121° C)
53260
Model 326

LOAD DEFLECTION CHART



Model
No.
EDP
No.
Holding
Capacity
Weight
326 53260 8 lbs. .07 lbs.
336 53360 12 lbs. .16 lbs
346 53460 25 lbs. .36 lbs.
