These
Electric/Hydraulic Pumps are twostage, continuous pressure (demand)
pumps that contain all the necessary controls and circuitry for
powering any singleacting or doubleacting continuous pressure
workholding system. They have a pressure switch and an external
pressure regulator, both infinitely adjustable throughout the
operating pressure range of 1,000 to 5,000 psi. An internal safety
relief valve prevents damage from exceeding the maximum rated
pressure.
They
are gerotor/axial piston pumps with a totally enclosed fan cooled
(TEFC) induction motor. Shipped with two gallons of hydraulic
oil.
Features:
- NEMA
12 electrical enclosure and controls
- CSA
approved
- Drip/chip
cover
- Liquidfilled
gauge
- Dual
carrying handles
- Thermal
overload protection
- 2.5gallon
metal reservoir
- 44
cu. in./min. oil flow at max. pressure
- 590
cu. in. usable oil
- SAE
#4 Outlet Manifold Ports
|
