DESTACO’s
Work Supports provide the stability that prevents deflection and
vibration of the workpiece during machining. Automatically adjustable
to verying sizes or positions of the workpieces, they are also
unsable as adjustable rest pads under clamps.
These
7,500 lb. work supports are available in three different Spring
Advanced models with either conventional or manifold mounting.
All use plunger seals to protect against contamination. The spring
advanced models use DE STA CO's diaphragm breather system.
The
block style design requires only a flat surface for mounting rather
than the large threaded hole necessary with threaded body designs.
Features:
- Spring
Advanced Models
- 7,500
lbs. rated capacity at 5,000 psi max.
- Single
acting
- Manifold
or conventionally mounted styles
- Sealed
against contamination
|
