STA CO's flange mounting brackets allow you to secure your wing/pull
clamps in two ways. You may use the set screw and nylon thread protector
ball (supplied) or simply lock the clamp using an optional jam nut.
Flange Mounting Brackets
Dimensions (In Inches)
Cat. No.
A
B
C
D
E
F
G
H
J
K
L
Thread Size
M
Dia.
N
Thread Size
100979DE
1.593
1.500
.500
.750
.750
.560
1.120
.200
.250
.750
11⁄1616 UNC
.222
100127DE
1.875
1.750
.875
.938
.703
1.406
.875
11⁄412 UNF
.219
1⁄420 UNC
100114DE
2.750
2.500
1.000
1.250
1.375
1.000
2.000
.265
.500
1.250
17⁄816 UN
.281
100914DE
3.500
3.250
1.250
1.625
1.750
1.250
2.500
.500
.625
1.625
21⁄216 UN
.406
Note:
Includes locking set screw and nylon ball to protect clamps threads
