During clamp retraction, the cylinder rod rotates 90°
causing the clamping arm to swing into
position. Clamping then takes place as the rod continues to retract in a straight line, pulling the arm against the workpiece.
The optional arms clamp securely to the piston rod to reduce
fatigue and deflection. Arms may be easily modified or replaced with custom arms.
Special rod wiper and a unique drainage system channels contaminants away from the clamp.
Available 90°
left hand or right hand rotation, or with guided straight pull.
